Tubular copper cable lug T

Tubular copper cable lug with a tinned surface finish, designed to provide safe and reliable electrical connections by compression crimping. Made from high-conductivity electrolytic copper, it features an inspection hole that allows the correct conductor insertion to be checked before crimping.

  • 99.9% electrolytic copper
  • Tinned surface finish
  • Compression crimping
  • Inspection hole


What is a T tubular copper cable lug?

The T-type tubular copper cable lug is designed for connecting copper conductors by crimping. It is manufactured from high-conductivity electrolytic copper tube and features a tinned surface finish that promotes reliable electrical contact and provides protection against corrosion.

It is suitable for flexible and rigid copper conductors. It also features an inspection hole that allows the correct conductor insertion to be visually checked before crimping.

According to IEC 61238-1-1 standard.
UL certified.


Key benefits

High electrical conductivity

Made from high-conductivity electrolytic copper to ensure efficient current transfer.

Corrosion protection

The tinned surface finish provides protection against corrosion and helps maintain reliable electrical contact.

Visual installation check

The inspection hole allows the correct conductor insertion to be checked before crimping.

Secure and durable connection

Compression crimping provides a mechanically strong and stable connection.



Applications

T-type tinned copper cable lugs are designed for connecting copper conductors to busbars, copper bars and other connection points.

Typical applications include:

  • Electrical distribution networks.
  • Underground networks.
  • Electrical panels.
  • Industrial installations.
  • Power applications.



Class A cable lugs

Class A cable lugs are intended for electrical distribution networks and industrial applications where they may be subjected to short-circuit currents of relatively high magnitude and duration.



How to select the right T cable lug

To select the correct T tubular copper cable lug, the conductor characteristics, connection point and crimping system must be taken into account.

The main factors to consider are:

  • Conductor cross-sectional area.
  • Conductor diameter.
  • Connection bolt diameter.
  • Cable lug dimensions.
  • Conductor type.
  • Required crimping tool and die.



Frequently asked questions about T copper cable lugs


What is a tubular copper cable lug used for?

It is used to make electrical connections between copper conductors and busbars, copper bars or other connection points by crimping.


Which conductors are compatible with T cable lugs?

T-type cable lugs are suitable for flexible and rigid copper conductors. The correct lug must be selected according to the conductor cross-sectional area and characteristics.


Why are copper cable lugs tinned?

The tin coating provides protection against corrosion and helps ensure reliable electrical contact.


How is a T copper cable lug installed?

Installation is carried out by compression crimping, using the appropriate tool and die for the selected cable lug.








Ref. 1
Share it:

Specifications

Code Ref. Cross-section
(mm²)		 Dimensions (mm) kg
x 100		 Bag Box
ØI L ØT A C1 C2
010100 T-1,5/4 1,5 4 1,8 18,0 4,3 8,7 5,0 4,0 0,074 100 3000
010110 T-1,5/5 1,5 5 1,8 18,5 5,3 8,7 5,0 4,5 0,071 100 3000
010120 T-1,5/6 1,5 6 1,8 20,0 6,4 11,0 6,0 5,0 0,081 100 2000
010130 T-2,5/4 2,5 4 2,7 18,0 4,3 8,7 5,0 4,0 0,111 100 2000
010140 T-2,5/5 2,5 5 2,7 19,0 5,3 8,7 5,5 4,5 0,112 100 2000
010150 T-2,5/6 2,5 6 2,7 20,0 6,4 9,0 6,0 5,0 0,110 100 1800
010160 T-2,5/8 2,5 8 2,7 24,0 8,3 12,0 8,0 7,0 0,128 100 1800
010170 T-4/4 4 4 3,3 21,0 4,3 8,7 5,0 4,5 0,168 100 1600
010180 T-4/5 4 5 3,3 21,0 5,3 8,7 5,0 4,5 0,163 100 1600
010190 T-4/6 4 6 3,3 23,0 6,4 11,0 6,0 5,5 0,171 100 1600
010200 T-4/8 4 8 3,3 26,5 8,3 14,0 8,0 7,0 0,179 100 1200
010210 T-6/4 6 4 3,8 23,0 4,3 10,3 6,0 5,0 0,204 100 1600
010220 T-6/5 6 5 3,8 23,0 5,3 10,3 6,0 5,0 0,202 100 1500
010230 T-6/6 6 6 3,8 24,0 6,4 10,3 6,0 5,5 0,200 100 1500
010240 T-6/8 6 8 3,8 27,0 8,3 14,0 8,0 7,0 0,208 100 1300
010260 T-10/5 10 5 4,7 25,5 5,3 11,9 6,0 5,5 0,364 100 1000
010270 T-10/6 10 6 4,7 27,0 6,4 11,9 7,0 6,0 0,361 100 1000
010280 T-10/8 10 8 4,7 30,0 8,3 15,0 8,0 8,0 0,388 100 800
010290 T-10/10 10 10 4,7 34,0 10,5 18,0 10,5 9,5 0,414 100 600
010310 T-16/5 16 5 5,6 26,5 5,3 11,9 6,0 5,0 0,465 100 700
010320 T-16/6 16 6 5,6 28,5 6,4 11,9 7,0 6,0 0,489 100 700
010330 T-16/8 16 8 5,6 31,0 8,3 15,0 8,0 7,5 0,500 100 600
010340 T-16/10 16 10 5,6 34,5 10,5 18,0 10,0 9,0 0,524 100 500
010350 T-16/12 16 12 5,6 38,5 13,0 20,0 12,0 11,0 0,552 100 500
010360 T-25/6 25 6 7,1 31,0 6,4 13,5 7,0 6,0 0,700 50 450
010370 T-25/8 25 8 7,1 34,0 8,3 15,0 8,5 7,5 0,742 50 450
010380 T-25/10 25 10 7,1 39,0 10,5 18,0 11,0 10,0 0,811 50 400
010390 T-25/12 25 12 7,1 41,0 13,0 21,0 12,0 11,0 0,793 50 300
010410 T-35/6 35 6 8,7 34,0 6,4 15,7 7,0 6,0 1,081 50 300
010420 T-35/8 35 8 8,7 38,0 8,3 15,7 9,0 8,0 1,165 50 300
010430 T-35/10 35 10 8,7 42,0 10,5 19,0 11,0 10,0 1,221 50 200
010440 T-35/12 35 12 8,7 44,0 13,0 21,0 12,0 11,0 1,231 50 200
010450 T-35/14 35 14 8,7 48,0 14,5 21,0 14,0 13,0 1,315 50 200
010500 T-50/6 50 6 9,8 41,0 6,4 17,9 8,0 7,0 1,570 20 200
010510 T-50/8 50 8 9,8 43,0 8,3 17,9 9,0 8,0 1,591 20 180
010520 T-50/10 50 10 9,8 47,0 10,5 20,0 11,0 10,0 1,706 20 160
010530 T-50/12 50 12 9,8 51,0 13,0 21,0 13,0 12,0 1,746 20 160
010540 T-50/14 50 14 9,8 53,0 14,5 25,0 14,0 13,0 1,793 20 140
010550 T-50/16 50 16 9,8 55,0 16,5 26,0 15,0 14,0 1,771 20 140
010570 T-70/8 70 8 11,5 47,0 8,3 21,5 9,0 8,0 2,385 20 120
010580 T-70/10 70 10 11,5 51,0 10,5 21,5 11,0 10,0 2,510 20 120
010590 T-70/12 70 12 11,5 53,0 13,0 21,5 12,0 11,0 2,504 20 120
010600 T-70/14 70 14 11,5 58,0 14,5 25,0 15,0 13,0 2,698 20 100
010610 T-70/16 70 16 11,5 59,0 16,5 26,0 15,0 14,0 2,617 20 100
010630 T-95/8 95 8 13,5 52,0 8,3 24,7 10,0 9,0 3,354 20 80
010640 T-95/10 95 10 13,5 55,0 10,5 24,7 11,0 11,0 3,387 20 80
010650 T-95/12 95 12 13,5 57,0 13,0 24,7 12,0 12,0 3,468 20 80
010660 T-95/14 95 14 13,5 61,0 14,5 24,7 15,0 13,0 3,622 20 80
010670 T-95/16 95 16 13,5 64,0 16,5 27,0 16,0 15,0 3,690 20 80
010690 T-120/8 120 8 15,6 56,0 8,3 28,9 10,0 9,0 5,357 10 60
010700 T-120/10 120 10 15,6 58,0 10,5 28,9 11,0 10,0 5,452 10 60
010710 T-120/12 120 12 15,6 63,0 13,0 28,9 14,0 12,0 5,800 10 60
010720 T-120/14 120 14 15,6 67,0 14,5 28,9 16,0 14,0 6,068 10 60
010730 T-120/16 120 16 15,6 71,0 16,5 28,9 17,0 16,0 6,296 10 60
010750 T-150/10 150 10 16,5 69,0 10,5 30,4 13,0 11,0 7,125 10 50
010760 T-150/12 150 12 16,5 75,0 13,0 30,4 16,0 14,0 7,749 10 50
010770 T-150/14 150 14 16,5 79,0 14,5 30,4 18,0 16,0 7,891 10 50
010780 T-150/16 150 16 16,5 79,0 16,5 30,4 18,0 16,0 7,694 10 40
010800 T-185/10 185 10 18,8 74,0 10,5 34,0 13,0 11,0 9,842 10 40
010810 T-185/12 185 12 18,8 80,0 13,0 34,0 16,0 14,0 10,447 10 40
010820 T-185/14 185 14 18,8 84,0 14,5 34,0 18,0 16,0 10,991 10 40
010830 T-185/16 185 16 18,8 85,0 16,5 34,0 18,0 17,0 10,831 10 40
010850 T-240/10 240 10 21,2 82,0 10,5 38,4 14,0 12,0 12,466 5 25
010860 T-240/12 240 12 21,2 86,0 13,0 38,4 16,0 14,0 12,916 5 25
010870 T-240/14 240 14 21,2 90,0 14,5 38,4 18,0 16,0 13,352 5 25
010880 T-240/16 240 16 21,2 91,0 16,5 38,4 18,0 17,0 13,198 5 25
010900 T-300/12 300 12 23,4 93,0 13,0 41,7 16,0 14,0 15,780 5 15
010910 T-300/14 300 14 23,4 94,0 14,5 41,7 16,0 15,0 17,249 5 15
010920 T-300/16 300 16 23,4 100,0 16,5 41,7 19,0 18,0 18,161 5 15
010940 T-400/12* 400 12 26,8 110,0 13,0 47,8 21,0 19,0 24,560 5 10
010950 T-400/16* 400 16 26,8 110,0 16,5 47,8 21,0 19,0 24,246 5 10
010960 T-400/20* 400 20 26,8 116,0 21,0 47,8 24,0 22,0 25,010 5 10
010980 T-500/16* 500 16 29,8 115,0 16,5 54,8 22,0 19,0 42,990 1 9
010985 T-500/20* 500 20 29,8 120,0 21,0 54,8 24,0 22,0 46,702 1 9
010988 T-630/16* 630 16 34,5 128,0 16,5 64,4 22,0 19,0 66,260 1 5
010990 T-630/20* 630 20 34,5 134,0 21,0 64,4 24,0 23,0 68,680 1 5

* Do not comply with the UL certification.
