20202 EBC-13C

Electrohydraulic tools

412001

Battery-powered hydraulic crimping tool

  • C-shaped head that rotates 180 degrees.
  • 2-speed hydraulic system.
  • Independently designed oil return system can safety react without electricity.
  • The trigger switch and return button are separately and activated by only one hand.
  • Built-in chip, with memory function, can stop automatically when crimping is completed, realize intelligent crimping.
  • Crimping cycle data is automatically stored on a memory card for transfer to PC by USB interface or bluetooth.
  • OLED display provides information on battery capacity, crimping cycles, and service cycles.
  • Automatic retraction when the maximum pressure is reached.
  • LED lightning for work in dark environments.
  • Rubber grip to have low noise and minimal vibration.
  • Include tool holder briefcase.

Available dies

HD13 copper and aluminium cable lugs and butt-connectors by hexagonal compression
Copper: up to 400 mm²
Aluminium: up to 300 mm²
Bimetallic: up to 240mm²

CD13 copper and aluminium compression clamps by circular compression
Copper: main up to 185 mm² and tap up to 185 mm²
Aluminium: main up to 300 mm² and tap up to 70 mm²


Ref. 617
Share it:

Specifications
