30903 SHUNT

SHPC clamp for insulated cable
Designed to pierce the conductor insulation without the need for stripping.
It provides a direct and secure connection on low-voltage cables.
Fully insulated, with retractable protection.

SHCD clamp for bare cable
Specially designed for direct connection onto bare conductors.
It provides a firm and secure contact.
Fully insulated, with retractable protection.

SHPL clamp for busbars
Suitable for connection on busbars or flat bars.
Its design ensures a stable and conductive grip.
Ideal for electrical panels and substations.


Mod. SHPC
Dimensions: 143 x 54 x 26 mm
Capacity: Ø 25 - 240 mm²
Point proof: Taking 4 mm
Splice: Connecteur M8
Max. working current: 200 A
Voltage Max.: 1000 V
Weight: 250 g

Mod. SHCD
Dimensions: 143 x 54 x 26 mm
Capacity: Ø 25 - 240 mm²
Point proof: Taking 4 mm
Splice: Connecteur M8
Max. working current: 200 A
Voltage Max.: 1000 V
Weight: 250 g

Mod. SHPL
Dimensions: 143 x 54 x 26 mm
Capacity: 2 - 25 mm
Point proof: Taking 4 mm
Splice: Connecteur M8
Max. working current: 200 A
Voltage Max.: 1000 V
Weight: 250 g
