Cutting unit
The KH-140-VOLTCUT model is a battery-powered hydraulic cutting tool, designed for precise and safe cutting of copper and aluminium cables, including armoured cables and cables under voltage up to 220 kV.
Includes:
- Hydraulic cutting head: Ø140 mm, 25 tonnes, rotary locking design.
- Battery hydraulic pump: provides an operating pressure of 70 MPa.
- High-pressure insulated hose: 10 m, prefilled with insulating oil.
- Wireless remote control: enhances operator safety with extended range.
- Grounding cable: 6 m copper cable with reinforced terminal end.
- Grounding rod: 1 m length with carrying bag.
- Carrying backpack: provides comfort, durability and protection for the hydraulic pump.
- Plastic transport case: with wheels for easy movement, designed for the cutting head and hose.
- Nylon protective bag: for the grounding rod.
