20203 CH-13U

Hydraulic head 13T


• Universal crimping head for all types of crimping, including deep stepped crimping, made of specially treated hermetically sealed steel.
• Flip-top head: Simplifies the positioning and insertion of the dies.
• Quick Snap-Lock Connection: Features a non-detachable dust cap for convenience.
• Deep Indent Crimping Tools: Possibility to use with adapters and a punch for precise crimping.
• Comes with adapter for hexagonal crimping.
• Include tool holder briefcase.

Available dies

HD13 Copper and aluminium cable lugs and butt-connectors by hexagonal compression
Up to 400 mm² copper
Up to 300 mm² aluminium
Up to 240 mm² aluminium

CD13 Copper and aluminium Compression clamps by circular compression
Copper: Up to 185 mm²
Aluminium: Main up to 300 mm² and tap up to 70 mm²

MP-L/PP Bimetallic cable lugs by deep punching compression
Up to 240 mm²

MP-S/PP Aluminium multi voltage joints by deep punching compression
Up to 240 mm²


Note: choose the adapter according to the cable section, to be used together with the corresponding punch and die.
