20105 KC-13/45 CT

KIT KC-13/45 CT
Crimping and cutting heads


• This KIT combines the CH-13C and CT-45 hydraulic heads, offering a versatile solution for crimping and cutting tasks.
• Designed for use with external hydraulic pumps, it is ideal for the EB-7 model but also compatible with other hydraulic pumps operating at 700 bar. Its design allows the operator to easily switch between heads as needed, maximizing efficiency and reducing costs.
• This KIT is the perfect solution for professionals who need a compact, efficient, and versatile hydraulic tool compatible with a wide range of external pumps.
• It includes a secure and organised carrying case with additional space for crimping dies (not included in this KIT).

KIT Components

Head CH-13C (Cod. 413001)

Hydraulic “C”-shaped head designed for high-pressure crimping of copper, aluminum, and bimetallic terminals and connectors (hexagonal crimping only).


• Crimping force: Up to 130 kN
• Crimping range: Up to 400 mm² (copper), up to 300 mm² (aluminum), up to 240 mm² (bimetallic in hexagonal compression mode)
• Branching sleeves: Up to 300 mm² (aluminum) and 240 mm² (copper)
• Maximum pressure: 700 bar
• Head dimensions: 289 x 119 x 72 mm
• Head weight: 5.43 kg

Head CT-45 (Cod. 20203003)

Hydraulic cutting head, ideal for cutting copper, aluminum, and ACSR cables.


• Cutting force: 60 kN
• Cutting capacity: Copper (CU), aluminum (AL), and ACSR cables up to 45 mm in diameter
• Steel bars up to 20 mm in diameter
• Maximum pressure: 700 bar
• Head dimensions: 310 x 100 x 70 mm
• Head weight: 3.8 kg

Ideal compatibility

The KIT has been designed to maximize the features of the EB-7 portable hydraulic pump, highlighting its efficiency, ease of use, and portability. However, it can also be used with other hydraulic pumps operating at a pressure of up to 700 bar, ensuring flexibility in its application.

Advantages

Interchangeability: Allows quick switching between cutting and crimping tasks, adapting to various operational needs.
Robustness & Durability: Made from high-quality materials to withstand demanding conditions.
This KIT is the perfect solution for operators who need a versatile, compact, and efficient hydraulic tool, compatible with a wide range of external hydraulic pumps.
