Equipment with MC automatic clamps - 4 clamps
Four-MC-clamp configuration for tasks requiring earthing and short-circuiting of two spans or two points.
According to IEC 61230 standard.
Composed of:
- 4 MC aluminium-alloy clamps with automatic spring activation. For cylindrical conductors with diameters between 3 and 20 mm.
- 1 clamp holder plate with recovery hook.
- 3 copper PVC-insulated cables, 2.5 m long, cross-section depending on model (16, 25, 35 mm²).
- 1 copper PVC-insulated cable, 15 m long, cross-section depending on model (16, 16, 25 mm²).
- 1 metal reel to house the 15 m earthing cable.
- 1 telescopic pole (1.10 m retracted, 2 m extended).
- 1 earthing rod.
- 1 plastic case for storing and transporting the equipment (optional with wheels).
- 1 carrying cover for the pole and earthing rod.
