31003 SYNCRO

Wireless detector for phase concordance verification of a network, it allows to control all types of three-phase networks from 1 to 79 kV.
Maximum functional reliability offering the possibility of measurement even through obstacles, such as walls, doors, etc.
Guaranteed detection distance up to 50 m.

According to UNE-EN 61481-1:2015 standard.

31003 SYNCRO

• Voltage range: from 1 to 79 kV
• Frequency: 50 - 60 Hz
• Use: Indoor/Outdoor use with the insulating pole according to model/range of voltage of the testers used.
• Signaling: Optical and acoustic by LED diodes and buzzer.
• Class A: ±10º < φp ≤ ± 30º
• Climatic category: N, climatic conditions of use and storage, temperature from -25ºC to +55ºC, humidity from 20 to 96 %.
• Power supply: AA LR06 type battery, automatic disconnection system sleep mode (battery saving).
• Self-verification: Integrated device for self-verification of operation.
