20203 KIT CH-20P

Hydraulic heads and pumps

413009


Hydraulic head with die set for bimetallic terminals 300/400 mm²

  • The universal CH‑20P 20‑ton hydraulic head is designed for all types of crimping applications, including hexagonal crimping, deep punching and circular crimping. Ideal for conductor cross‑sections up to 630 mm² Cu/Al, through the use of different adapters it ensures versatile compatibility.
  • The KIT 413009 includes the adapter, die and punch for crimping bimetallic terminals of 300 and 400 mm² (TDC/S‑300, TDC/S‑400, TBF‑300 and TBF‑400) according to standards UNE 211024‑2 and NF C33‑090‑1.
  • Carrying case included.


Available dies

DPA-300/630 adapter for deep punching
300/630mm²
Code: 406013

DPD-300/400L deep punch die
300/400mm²
Code: 406014

DPP-300/400 5E punch for deep punching
300/400mm²
Code: 406015


Ref. 714
Share it:

Specifications
