Three-phase equipment for LV/MV substations with MPUL clamps
Set with three MPUL clamps (screw tightening and insulated handle) and protected branch connector.
Designed for busbars or cylindrical conductors in transformer substation cells.
According to IEC 61230 standard.
Composed of:
- 4 MPUL aluminium-alloy clamps with screw tightening and insulated handle.
- 3 copper PVC-insulated cables, 95 mm² cross-section, 1 m, 0.7 m, and 0.55 m long.
- 1 copper PVC-insulated cable, 95 mm² cross-section, 0.75 m long.
- 1 protected branch connector with rubber housing.
- 1 bag for storing and transporting the equipment.
