Four SHUNT clamp version, for short-circuiting the three phases and earthing the neutral. SHCD or SHPL clamps for bare wire or busbars, providing a firm and conductive grip.
According to IEC 61230 standard.
Composed of:
- 4 insulated SHUNT earth clamps for short-circuiting the phases and neutral.
- 3 copper PVC-insulated cables, 25 mm² cross-section, 1.2 m long for phase short-circuiting.
- 1 copper PVC-insulated cable, 25 mm² cross-section, 1.5 m long for neutral earthing.
- 1 copper PVC-insulated cable, 25 mm² cross-section, 2 m long for earthing.
- 1 5-way branch-joint connector.
- 1 TT-38A earthing lathe.
- 1 plastic case for storing and transporting the equipment.
