TMC clamp set for conductor and bar up to 90 x 100 mm
TMC clamps suitable for cylindrical conductors (Ø 10-70 mm) and flat bars (max. 90 x 100 mm), with wide jaw opening.
According to IEC 61230 standard.
Composed of:
- 3 TMC aluminium alloy clamps with screw tightening. For cylindrical conductors with diameters between 10 and 70 mm, flat bars up to 90 x 100 mm, and inclined plates up to 50 x 120 mm.
- 3 copper cables with PVC insulation. Section and length depending on model.
- 3 TT-50 earthing lathes.
- 3 bags for storing and transporting the equipment.
Selection of the hot stick:
High-voltage earthing equipment is supplied without an insulating hot stick. The hot stick must be selected according to the system voltage, in accordance with applicable regulations, to ensure safe distances and proper ergonomics during operations.
