Equipment with PA40-B Bayonet clamps for large diameters
PA40-B screw-type clamps with bayonet spindle for conductors or tubes with diameters from 36 to 130 mm, suitable for HV applications.
According to IEC 61230 standard.
Composed of:
- 3 PA40-B (Bayonet) aluminium alloy clamps with screw tightening, for cylindrical conductors with diameters between 36 and 130 mm.
- 3 copper cables with PVC insulation, section and length depending on model.
- 3 TT-50 earthing lathes.
- 3 nylon bags for storing and transporting the equipment.
Selection of the hot stick:
High-voltage earthing equipment is supplied without an insulating hot stick. The hot stick must be selected according to the system voltage, in accordance with applicable regulations, to ensure safe distances and proper ergonomics during operations.
