Set with MPL clamps for substations
MPL aluminium clamps with screw tightening; wide range of cable sections and Lengths available to suit ICC requirements and reach.
According to IEC 61230 standard.
Composed of:
- 3 MPL aluminium alloy clamps with screw tightening. For cylindrical conductors with diameters between 5 and 45 mm, and flat bars.
- 3 copper cables with PVC insulation. Section and length depending on model.
- 3 TT-50 earthing lathes.
- 3 bags for storing and transporting the equipment.
Selection of the hot stick:
High-voltage earthing equipment is supplied without an insulating hot stick. The hot stick must be selected according to the system voltage, in accordance with applicable regulations, to ensure safe distances and proper ergonomics during operations.
