Equipment with 5014H steerable clamps
Multidirectional head that allows adjusting the clamp angle to access busbars or conductors in different positions. Includes a branch connector with rubber housing.
According to IEC 61230 standard.
Composed of:
- 3 5014H brass steerable clamps with screw tightening and Hex-12 shaft, for cylindrical conductors with diameters between 5 and 25 mm.
- 3 copper PVC-insulated cables, 25/35/50 mm² cross-section (depending on model), 0.75 m long.
- 1 copper PVC-insulated cable, 25/35/50 mm² cross-section (depending on model), 2 m long.
- 1 insulated trifurcating connector with rubber housing.
- 1 TT-38A earthing lathe.
- 1 1.5 m telescopic pole, three sections.
- 1 plastic case for storing and transporting the equipment (optional with wheels).
