Earthing equipment for overhead lines (single-operator operation)
System with telescopic metal poles featuring self-locking clamps (Ø 3-22 mm), pole lifter, and pegs; allows single-operator use and voltage absence testing with a detector (not included).
According to IEC 61230 standard.
Composed of:
- 3 telescopic metal poles, each composed of 3 sections, with a self-locking fixed contact clamp for conductors with diameters between 3 and 22 mm
- 1 insulating fiberglass pole with epoxy resin, filled with polyurethane foam, in 3 sections of 1.72 + 1.65 + 1.63 m; certified according to IEC 60855. Total length: 5 m (option to use without the middle section, giving a total length of 3.4 m).
- 1 pole holder.
- 1 reel with 3 copper cables, 35 mm² cross-section, 10 m length.
- 2 galvanised steel earthing rods, hexagonal section, 1 m each.
- 1 insulating pole support.
- 1 carrying bag.
